Our knob adjustable variable-height platforms feature a 2 to 4 inch height range with with 0.002 in. resolution. They lock solidly and can support up to 50 lbs.
| Compare | Model | Drawings, CAD & Specs | Availability | Price | |||
|---|---|---|---|---|---|---|---|
|
Variable Height Platform, 2 in. Travel, 3 x 3 in. Platform, 220 N Load, 8-32 and 1/4-20
$511.00
In Stock
|
9204 Variable Height Platform, 2 in. Travel, 3 x 3 in. Platform, 220 N Load, 8-32 and 1/4-20 |
In Stock
|
$511.00 |
|
||
|
|
Variable Height Platform, 2 in. Travel, 3 x 3 in. Platform, 220 N Load, M4 and M6
$511.00
In Stock
|
9204-M Variable Height Platform, 2 in. Travel, 3 x 3 in. Platform, 220 N Load, M4 and M6 |
In Stock
|
$511.00 |
|
| Models |
$511.00
In Stock
Product Series Overview
|
$511.00
In Stock
Product Series Overview
|
|---|---|---|
| Travel Range | 50.8 mm | 50.8 mm |
| Minimum Height | 50.8 mm | 50.8 mm |
| Maximum Height | 101.6 mm | 101.6 mm |
| Resolution | 0.05 mm | 0.05 mm |
| Platform Size | 76.2 x 76.2 mm | 76.2 x 76.2 mm |
| Load Capacity | 220 N | 220 N |
| Thread Type | 8-32 and 1/4-20 | M4 and M6 |
Each revolution of the adjustment knob corresponds to 0.25 in. of vertical travel. The platform can be adjusted to be between 2 and 4 inch height.
A locking screw on the side of the adjustment knob allows the platform height to be securely fixed.
The base of the big lab jack has 1/4-20 (M6) through holes for mounting to metric or imperial optical tables or breadboards.
