The LTA-HS High Speed Motorized Actuator is optimized for high-speed applications and provides a 50 mm travel range. LTA actuators are designed to fit into selected manual stages and other opto-mechanical components as direct replacement for manual micrometers. It features a space-saving design with the motor and lead screw mounted side-by-side. This reduces the actuator length by 50% and minimizes the unwanted effects of long cantilever loads on micro-positioning equipment. Precision motion is accomplished through a miniature DC servo motor with optimized output torque. This allows for faster motion and high load capacity.
LTA Series motorized actuators provide a manual adjustment knob which permits quick positioning of the actuator when the motor is off.
LTA Actuators include a visible scale that indicates coarse actuator position in both millimeters and inches. Beneath the scale's window is an accessible trigger which, along with the Manual Adjustment Knob, can be manually set to limit the actuator's travel range.
LTA actuators feature a non-rotating tip that prevents wear and eliminates periodic motion variations when the actuator is moving.
| Compare | Description | Compatibility | Drawings, CAD & Specs | Avail. | Price | |||
|---|---|---|---|---|---|---|---|---|
 |
SMC100CC Motion Controller, Single-axis DC Motor | UNIVERSAL |
In Stock
|
$1,383.00 |
|
|||
 |
433 Linear Stage, High-Performance, Low-Profile, 1.81 in. Travel, 1/4-20 | IMPERIAL |
In Stock
|
$415.00 |
|
|||
 |
SMC-PS80 Power Supply, SMC100 Series, 80W, 100-240 VAC, 47-63 Hz, 1.9 A max. | UNIVERSAL |
In Stock
|
$176.00 |
|
|||
 |
TRA25CC Motorized Actuator, Miniature, 25 mm Travel, DC Servo Motor | UNIVERSAL |
In Stock
|
$1,133.00 |
|
|||
 |
436 Manual Linear Stage, Crossed-Roller Bearings, 2.0 in. Travel, 1/4-20 | IMPERIAL |
In Stock
|
$954.00 |
|
|||
 |
LTA-M12 Mounting Adapter, LTA-HS to UMR8, MVN80 and SL | UNIVERSAL |
In Stock
|
$107.00 |
|
Based on axis required, choose a specific controller to pair with the stage. Along with an XPS-D or XPS-RLD controller, a driver module is required.
| Compare | Description | Compatibility | Drawings, CAD & Specs | Avail. | Price | |||
|---|---|---|---|---|---|---|---|---|
 |
XPS-RLD Universal High-Performance 1-4 Axis Motion Controller and Driver 1 | UNIVERSAL | ||||||
 |
XPS-D Universal High-Performance 1-8 Axis Motion Controller and Driver 2 | UNIVERSAL | ||||||
 |
ESP302 3-Axis DC and Stepper Motion Controller | UNIVERSAL | ||||||
| |
SMC100CC Motion Controller, Single-axis DC Motor | UNIVERSAL |
In Stock
|
$1,383.00 |
|
| Compare | Description | Compatibility | Drawings, CAD & Specs | Avail. | Price | |||
|---|---|---|---|---|---|---|---|---|
 |
BM17.51 Micrometer Head, Standard Resolution, 51 mm Travel, 23 lb. Load | UNIVERSAL |
In Stock
|
$304.00 |
|
|||
| |
TRA25CC Motorized Actuator, Miniature, 25 mm Travel, DC Servo Motor | UNIVERSAL |
In Stock
|
$1,133.00 |
|
|||
 |
LTA-HL Motorized Actuator, High Load, 25 mm travel, LTA, M12 thread | UNIVERSAL |
In Stock
|
$2,564.00 |
|
|||
 |
CONEX-LTA-HS Motorized Actuator, LTA-HS Integrated with CONEX-CC Controller | UNIVERSAL |
In Stock
|
$3,287.00 |
|
|||
| |
TRA25PPD Motorized Actuator, Miniature, 25mm Travel, Stepper, 25-pin D-Sub | UNIVERSAL |
In Stock
|
$1,133.00 |
|
|||
 |
CONEX-TRA25CC Linear Actuator, DC Servo, 25 mm Travel, TRA25CC and CONEX-CC Controller | UNIVERSAL |
In Stock
|
$1,775.00 |
|
| Compare | Description | Compatibility | Drawings, CAD & Specs | Avail. | Price | |||
|---|---|---|---|---|---|---|---|---|
| |
SMC100CC Motion Controller, Single-axis DC Motor | UNIVERSAL |
In Stock
|
$1,383.00 |
|
|||
 |
XPS-DRV01 PWM Drive Module, DC and Stepper Motors | UNIVERSAL |
In Stock
|
$907.00 |
|
|||
 |
561D-XYZ Fiber Alignment Stage, ULTRAlign, Right-Handed, 6 mm XZ 13 mm Y Travel, 8-32 | IMPERIAL |
In Stock
|
$2,588.00 |
|
