The SX200-R2KN-LH is a left-handed, rear-loading, stainless steel mount for 2-in (50.8-mm) diameter optics. It is sold with two non-locking 254-TPI adjustment screws for precision pitch/yaw positioning. 254-TPI adjustment screws provide a 60% sensitivity advantage over the standard adjusters while the new stainless steel alloy gives a 38% lower Coefficient of Thermal Expansion (CTE). The Suprema® XTE also has an optically black finish to reduce stray light reflections. SX200 mounts have superior adjustability and feel. Polished and lapped carbide pads enable smooth, repeatable motion. This two-actuator configuration has tip and tilt adjustability over a range of +/- 7 degrees. Convenient 8-32 (M4) counterbored clearance holes provide quick, precise, secure and stable mounting. SUPREMA mounts are compatible with standard post and post holder systems for adjustable height and pedestal posts for a stable fixed height.
UPA2-1Mirror Mount Adapter, 50.8 mm to 25.4 mm Diameter, For ULTIMA®
UNIVERSAL
In Stock
$42.00
A-2-1.5Optical Mount Adaptor, 50.8 mm to 38.1 mm (2 to 1.5 inch)
UNIVERSAL
In Stock
$80.00
TRA12PPDMotorized Actuator, Miniature, 12 mm Travel, Stepper, 25-pin D-Sub
UNIVERSAL
In Stock
$1,065.00
A-2-1Optical Mount Adaptor, 50.8 mm to 25.4 mm (2 to 1 inch)
UNIVERSAL
In Stock
$76.00
SX200-R2KN-LH - Drawings & CAD
Additional CAD file downloads are not available for this product.
SX200-R2KN-LH - Drawings
Additional drawings are not available for this product.
