Specifications

  • Lens Shape
    Plano-Convex
  • Lens Material
    Zinc Selenide (ZnSe)
  • Coating Type
    DURALENS™
  • Absorption
    <0.20%
  • Transmission
    >99.3%
  • Reflectivity
    <0.2%
  • Surface Accuracy, Irregularity
    0.5 Fringe @ 0.633 µm
  • Surface Figure
    2 Fringes @ 0.633 µm
  • Diameter Tolerance
    +0.0/-0.1 mm
  • Edge Thickness Tolerance
    ±0.1 mm
  • Clear Aperture
    ≥90%

Features

Virtual Tour of Ophir Optics Manufacturing Capabilities

Join us for a virtual tour at our Jerusalem production site to learn how we provide a one-stop-shop solution, from design to manufacture, assembly and QA, for optical components and assemblies to IR thermal imaging and high-power laser applications.

Resources

Literature

Technical Notes

CompareModelDrawings, CAD & Specs Diameter Focal Length Edge Thickness (Te) OEM Compatibility Availability Price
