HPF1260 Fluorescence Optical Filter Set

The HPF1260 HPF™ filter set includes HPX485-30

Excitation Filter, HPD515

Model: HPD515

Longpass Dichroic Filter, Fluorescence, 25.5 x 36 mm, 520-565 nm Trans.

$195.00

In Stock

See Full Product Details

Dichroic Filter, and HPM545-30

Emission Filter. It is ideal to use with Oregon Green™ fluorophores. HPF™ filters are manufactured using our patented Stabilife^® coating technology which provides excellent spectral performance, spectral stability, and physical durability. These filter sets are designed to provide maximum performance using several key features including:

Exceptionally high passband transmission
Maximized out-of-band blocking including extended range blocking on excitation filters
Extremely steep slopes from rejection to transmission regions
Optical finishing for maximum image rendition including precision grinding and polishing and anti-reflection coatings
Filter bandpass specifications of center wavelength and bandwidth providing maximum image brightness and minimum background.

These product designs have served as the starting point for custom designed filters for market leading instruments including DNA Sequencers, Cytometers, MicroPlate Readers, In vivo Imagers, and Thermocyclers.

Specifications

Technical Specs

Fluorophores

Oregon Green™

Fluorophores

Oregon Green™

Resources & Downloads

Other

HPF1260 RoHS Certificate (265 kB, PDF)

Literature

Fluorescence Filters Brochure (2.1 MB, PDF)

Related Products

Fluorescence Filter Set Components

The following fluorescence filters are included with this set.

Description	Compatibility	Avail.	Price
HPX485-30 Bandpass Filter, Fluorescence, 25.0 mm, 485 nm Center, 30 nm Bandwidth	UNIVERSAL	In Stock	$306.00
HPD515 Longpass Dichroic Filter, Fluorescence, 25.5 x 36 mm, 520-565 nm Trans.	UNIVERSAL	In Stock	$195.00
HPM545-30 Bandpass Filter, Fluorescence, 25.0 mm, 545 nm Center, 30 nm Bandwidth	UNIVERSAL	In Stock	$306.00

Fluorescence Optical Filter Set, Oregon Green™
