HPF1305 Fluorescence Optical Filter Set

The HPF1305 HPF™ filter set includes HPX530-40

Excitation Filter, HPD560

Dichroic Filter, and HPM600-60

Emission Filter. It is ideal to use with BODIPY TMR fluorophores. HPF™ filters are manufactured using our patented Stabilife^® coating technology which provides excellent spectral performance, spectral stability, and physical durability. These filter sets are designed to provide maximum performance using several key features including:

Exceptionally high passband transmission
Maximized out-of-band blocking including extended range blocking on excitation filters
Extremely steep slopes from rejection to transmission regions
Optical finishing for maximum image rendition including precision grinding and polishing and anti-reflection coatings
Filter bandpass specifications of center wavelength and bandwidth providing maximum image brightness and minimum background.

These product designs have served as the starting point for custom designed filters for market leading instruments including DNA Sequencers, Cytometers, MicroPlate Readers, In vivo Imagers, and Thermocyclers.

Specifications

Technical Specs

Fluorophores

BODIPY TMR

Fluorophores

BODIPY TMR

Resources & Downloads

Other

HPF1305 RoHS Certificate (264.1 kB, PDF)

Literature

Fluorescence Filters Brochure (2.1 MB, PDF)

Related Products

Fluorescence Filter Set Components

The following fluorescence filters are included with this set.

Description	Compatibility	Avail.	Price
HPX530-40 Bandpass Filter, Fluorescence, 25.0 mm, 530 nm Center, 40 nm Bandwidth	UNIVERSAL	In Stock	$306.00
HPD560 Longpass Dichroic Filter, Fluorescence, 25.5 x 36 mm, 575-650 nm Trans.	UNIVERSAL	In Stock
HPM600-60 Bandpass Filter, Fluorescence, 25.0 mm, 600 nm Center, 60 nm Bandwidth	UNIVERSAL	5 Weeks	$195.00

Fluorescence Optical Filter Set, BODIPY TMR
