HPF1315 Fluorescence Optical Filter Set

The HPF1315 HPF™ filter set includes HPX535-50

Excitation Filter, HPD565

Model: HPD565

Longpass Dichroic Filter, Fluorescence, 25.5 x 36 mm, 587-650 nm Trans.

$195.00

In Stock

See Full Product Details

Dichroic Filter, and HPM620-60

Emission Filter. It is ideal to use with Dil(rs) fluorophores. HPF™ filters are manufactured using our patented Stabilife^® coating technology which provides excellent spectral performance, spectral stability, and physical durability. These filter sets are designed to provide maximum performance using several key features including:

Exceptionally high passband transmission
Maximized out-of-band blocking including extended range blocking on excitation filters
Extremely steep slopes from rejection to transmission regions
Optical finishing for maximum image rendition including precision grinding and polishing and anti-reflection coatings
Filter bandpass specifications of center wavelength and bandwidth providing maximum image brightness and minimum background.

These product designs have served as the starting point for custom designed filters for market leading instruments including DNA Sequencers, Cytometers, MicroPlate Readers, In vivo Imagers, and Thermocyclers.

Specifications

Technical Specs

Fluorophores

Dil(rs)

Fluorophores

Dil(rs)

Resources & Downloads

Other

HPF1315 RoHS Certificate (262.8 kB, PDF)

Literature

Fluorescence Filters Brochure (2.1 MB, PDF)

Related Products

Fluorescence Filter Set Components

The following fluorescence filters are included with this set.

Description	Compatibility	Avail.	Price
HPX535-50 Bandpass Filter, Fluorescence, 25.0 mm, 535 nm Center, 50 nm Bandwidth	UNIVERSAL	In Stock	$306.00
HPD565 Longpass Dichroic Filter, Fluorescence, 25.5 x 36 mm, 587-650 nm Trans.	UNIVERSAL	In Stock	$195.00
HPM620-60 Bandpass Filter, Fluorescence, 25.0 mm, 620 nm Center, 60 nm Bandwidth	UNIVERSAL	In Stock	$195.00

Fluorescence Optical Filter Set, Dil(rs)
