HPF1380 Fluorescence Optical Filter Set

The HPF1380 HPF™ filter set includes HPX605-40

Excitation Filter, HPD635

Model: HPD635

Longpass Dichroic Filter, Fluorescence, 25.5 x 36 mm, 647-710 nm Trans.

$254.00

In Stock

See Full Product Details

Dichroic Filter, and HPM670-50

Emission Filter. It is ideal to use with BODIPY 630/650 fluorophores. HPF™ filters are manufactured using our patented Stabilife^® coating technology which provides excellent spectral performance, spectral stability, and physical durability. These filter sets are designed to provide maximum performance using several key features including:

Exceptionally high passband transmission
Maximized out-of-band blocking including extended range blocking on excitation filters
Extremely steep slopes from rejection to transmission regions
Optical finishing for maximum image rendition including precision grinding and polishing and anti-reflection coatings
Filter bandpass specifications of center wavelength and bandwidth providing maximum image brightness and minimum background.

These product designs have served as the starting point for custom designed filters for market leading instruments including DNA Sequencers, Cytometers, MicroPlate Readers, In vivo Imagers, and Thermocyclers.

Specifications

Technical Specs

Fluorophores

BODIPY 630/650

Fluorophores

BODIPY 630/650

Resources & Downloads

Other

HPF1380 RoHS Certificate (264.5 kB, PDF)

Literature

Fluorescence Filters Brochure (2.1 MB, PDF)

Related Products

Fluorescence Filter Set Components

The following fluorescence filters are included with this set.

Description	Compatibility	Avail.	Price
HPX605-40 Bandpass Filter, Fluorescence, 25.0 mm, 605 nm Center, 40 nm Bandwidth	UNIVERSAL	In Stock	$306.00
HPD635 Longpass Dichroic Filter, Fluorescence, 25.5 x 36 mm, 647-710 nm Trans.	UNIVERSAL	In Stock	$254.00
HPM670-50 Bandpass Filter, Fluorescence, 25.0 mm, 670 nm Center, 50 nm Bandwidth	UNIVERSAL	In Stock	$306.00

Fluorescence Optical Filter Set, BODIPY 630/650
